DH Series

Standard doctor blade Excellent doctor blade

  • DHB1

    DHB1

    Application: Wet section of low speed paper machine and high speed paper machine

    Specialty: Excellent chemical resistance epoxy resin, excellent wear resistance, 160℃ temperature resistance

  • DHB2

    DHB2

    Application: Various rollers from the wirese ction to the coiling section

    Specialty: Microfiber combined with epoxy resin, Excellent chemical properties, 185℃ temperature resistance

  • DH-2C

    DH-2C

    Application: Drying cylinder, chrome roller, rubber roller, stone roller, etc.

    Specialty: Composed of 20% carbon fiber and glass fiber. Excellent flexible epoxy resin, which makes the blade and roll surface have excelle adhesion, 185℃ temperature resistance.

  • DH-4C

    DH-4C

    Application: Drying cylinder, chrome roller, rubber roller, stone roller, etc.

    Specialty: Composed of 40% carbon fiber and glass fiber. Excellent epoxy resin with strong self-lubricating 185℃ temperature resistance. Bending strength 760N/mm2.

  • DH-6C

    DH-6C

    Application: Drying cylinder chrome roller, rubber roller, stone roller, etc.

    Specialty: Composed of 60% carbon fiber and glass fiber. Excellent epoxy resin, strong self-lubricating 185℃ temperature resistance. Bending strength 830N/mm2.

  • DH-100C

    DH-100C

    Application: Ceramic rolls, mirror rolls and soft calender rolls

    Specialty: 100%carbon fiber pressed, excellent epoxy resin system. Extremely strong self-lubricating 185°C temperature resistance. Bending strength 1000N/mm2
